The Challenger A1073C arm restraint gear is the direct replacement for the Challenger lift it came off of. This is the genuine Challenger part — same fit and same working specification as the one already on your lift. Ordering the Challenger arm restraint gear from us gets you the OEM piece that matches the lift, not an aftermarket knock-off that is close but not the same.

Specifications

• Part number: A1073C
• Brand: Challenger
• Type: Genuine OEM arm restraint gear
• Fits: CL10, CL10A, CL10DPC, CL10V3, CLFP9

Lock parts wear slowly but steadily every time the lift cycles. Each engagement bangs the pawl against a tooth; over thousands of cycles the contact faces peen over and round off. Dirt and dried grease build up in the pivot until the pawl gets lazy. A commercial lift that racks up cycles all day will round its lock teeth years before a low-use lift does — but neglect and rust can age either one fast.

The locks are the lift's mechanical backup — the part that actually holds the vehicle up once it's raised. A spring-loaded pawl drops into a toothed ladder at each column, and the lift rests on steel, not on hydraulic pressure. Hydraulics raise the lift; the locks are what let you work under it. Every click you hear on the way up is a pawl catching a tooth, ready to catch the whole load if pressure is ever lost.

What lifts this arm restraint gear fits

This arm restraint gear fits the lift models below. Click a model to open its visual parts breakdown — the exploded drawing with every part numbered, so you can confirm this is the right part for your exact lift before you order.

• CL10 — see the exploded parts breakdown for this lift
• CL10A — see the exploded parts breakdown for this lift
• CL10DPC — see the exploded parts breakdown for this lift
• CL10V3 — see the exploded parts breakdown for this lift
• CLFP9 — see the exploded parts breakdown for this lift

Replacing your arm restraint gear

A sticky or worn pawl replacement means freeing or renewing the pawl, its pivot, and its return spring so it drops into the ladder without hesitation. Clean the mechanism, install the new parts, and test that the pawl snaps home and retracts fully on release. Because a lazy pawl is the difference between a lift that catches and one that doesn't, walk through the complete guide before you trust it. Full step-by-step: how to replace lift arm restraint gears.

Find the right part for your lift

Want to be sure before you buy? Pull the model and serial off your lift's plate and open our Challenger parts lookup to open the exploded parts breakdown for your model — find your part on the drawing and you know it fits. New to finding your model number? our guide to finding your model number covers it, or send a photo of the plate and we will read it for you.

Signs the locking system needs attention

Test engagement under the lift's own weight: raise it, then lower onto the locks and watch each pawl seat fully into a tooth. Any pawl resting on the tip or shoulder of a tooth instead of down in the root isn't fully engaged, even though it looks set. Shallow engagement usually traces to a worn tooth, a worn pawl nose, or the lift sitting unlevel.

Parts commonly replaced at the same time

Order lock parts as a group. Even, synchronized engagement depends on matched hardware on both columns, so the latch, pawl, spring, and release cable are best done together. It is cheaper in one pass, and we keep the right versions for your production run — one call gets the whole kit.

Safety notes

Do not run a lift whose locks do not click crisply and together. Worn pawls and stretched release cables let a carriage settle onto a tooth that is not fully seated — which is exactly how a lift fails under load. Adjust and replace lock parts as a set, and test engagement on both columns before the lift carries weight.

Before you order

A quick check before ordering: model, serial, and whether one or both columns need work. Lock designs vary by year, and matched hardware on both sides is what keeps engagement even. If your release cable is due too, add it now rather than reopening the column later.

Not sure this fits? Here's how to check

Pull the number off your lift's model plate first — model and serial both. Manufacturers run mid-cycle revisions that keep the model name but change hardware, so two lifts with the same name on the column can take different parts. The serial is what removes the guesswork.

Second check: compare the old part against this listing before you order. Length, mounting pattern, and thread sizes tell most of the story. If anything doesn't line up, or if the old part is too worn or broken to measure, call us with photos — we work on these lifts every week and can usually confirm fit from a picture and the lift's serial faster than you can dig through a parts diagram.

Why buy your Challenger arm restraint gear from Auto Lift Services

We install, inspect, and repair Challenger lifts every week — the A1073C is a part we handle in the shop, not a random SKU we drop-ship. The phone answers if you have a question mid-install — call 800-674-9302 — and every part ships genuine, no aftermarket substitution unless you ask for it.
