The Challenger B26027 hydraulic hose is the direct replacement for the Challenger lift it came off of. This is the genuine Challenger part — same fit and same working specification as the one already on your lift. Ordering the Challenger hydraulic hose from us gets you the OEM piece that matches the lift, not an aftermarket knock-off that is close but not the same.

Specifications

• Part number: B26027
• Brand: Challenger
• Type: Genuine OEM hydraulic hose
• Fits: CLFP9

Not every hydraulic problem is the cylinder. A lift that lowers itself overnight usually has a lowering valve that won't seat or a leaking check, not a bad seal. A lift that jerks or won't reach full height can be a tired pump or a flow valve out of adjustment. And a hose that's cracked near the crimp will spray under pressure — a real hazard, not just a mess to mop up.

The power unit bundles the motor, pump, reservoir, and valves into one hangable box, usually bolted to a column or a pump stand. Press up and the motor spins the pump, which draws fluid from the reservoir and sends it to the cylinder; release, and the dump valve routes it back. The single spec that matters most is voltage — 110 versus 220 — because the wrong one turns the whole unit into a paperweight.

What lifts this hydraulic hose fits

This hydraulic hose fits the lift models below. Click a model to open its visual parts breakdown — the exploded drawing with every part numbered, so you can confirm this is the right part for your exact lift before you order.

• CLFP9 — see the exploded parts breakdown for this lift

Replacing your hydraulic hose

A lowering or flow valve issue — a lift that drifts down or won't reach full height — is often fixed at the valve rather than the cylinder, but it takes a methodical check to be sure. Isolate whether the leak is internal or external, then service or replace the valve and confirm the lift holds height afterward. The step-by-step guide lays out how to trace it. Full step-by-step: how to replace a car lift hydraulic hose.

Find the right part for your lift

Landed here but not 100% sure it is your part? Grab the model and serial from the data plate and open our Challenger parts lookup for the visual breakdown — the manufacturer-style drawing with every item numbered so you can match yours exactly. Plate missing? our guide to finding your model number helps, and we identify lifts from photos every week if you would rather ask.

Signs of a hydraulic problem

Pull the reservoir cap and look at the fluid. Clear amber (or clean red for ATF) is good; milky or foamy means water has gotten in and the pump is aerating; dark and gritty means the system is wearing and the filter is loading up. Fluid condition tells you as much about the hydraulic health of the lift as any single part will.

Parts commonly replaced at the same time

One trip up, one refill, one bleed: order the companion hydraulic parts with this one. A seal kit alongside a cylinder, a fresh hose, and the correct oil turn a partial fix into a finished job. Tell us what lift you have and we will build the kit so nothing is left to fail next.

Hydraulic fluid

The usual fill is ISO-32 hydraulic oil, with some legacy lifts running Dexron ATF; confirm which your lift uses before topping off and keep the two separate. Bleed after filling and check the level again once the air is out — and see your manual for the exact capacity, which is model-specific.

Safety notes

Pressure and cleanliness are the two rules. Bleed the system completely so there is no air to compress, keep contamination out of every open port, and prove the lift holds at full height with no drift before it sees a vehicle. If you are not certain the bleed is complete, do it again — this is not the place to guess.

Before you order

Ordering tip: hydraulic parts are matched to the lift's pressure and geometry, so read the model and serial off the plate and, for hoses and cylinders, have the old part's dimensions. Plan to replace the oil and bleed the system as part of the job, and add a seal kit if you are opening the cylinder anyway.

Check your lift's serial before ordering

The most common reason a lift part comes back is not a defect — it is a revision mismatch. Manufacturers change sub-parts between production runs while keeping the same lift model name, so "it fits my lift model" is not always enough. The model plate carries the serial number that pins your lift to a specific run, and that is the number that settles which version of this part belongs on your lift.

Can't find the plate? Measure the old part — overall length, bolt-hole spacing, thread size on anything threaded — and photograph it from a couple of angles. Send that with your lift's brand and rough age and we will match it against the parts breakdowns we service from every week.

Why buy your Challenger hydraulic hose from Auto Lift Services

We install, inspect, and repair Challenger lifts every week — the B26027 is a part we handle in the shop, not a random SKU we drop-ship. The phone answers if you have a question mid-install — call 800-674-9302 — and every part ships genuine, no aftermarket substitution unless you ask for it.
