The Challenger TCS3-5-03-00 hydraulic cylinder is the direct replacement for the Challenger lift it came off of. This is the genuine Challenger part — same fit and same working specification as the one already on your lift. Ordering the Challenger hydraulic cylinder from us gets you the OEM piece that matches the lift, not an aftermarket knock-off that is close but not the same.

Specifications

• Part number: TCS3-5-03-00
• Brand: Challenger
• Type: Genuine OEM hydraulic cylinder
• Fits: Q4P07

Dirty or wrong fluid quietly wrecks hydraulic parts. Milky oil means water got in and the pump is cavitating; dark, gritty oil means the system is grinding itself and packing the filter with metal. Mixing ISO-32 and ATF, or topping off with whatever's on the shelf, changes the viscosity the pump was built for. Half the "bad cylinder" calls in a shop start as fluid that should have been changed years ago.

The cylinder is where hydraulic pressure becomes lift. Fluid pushed behind the piston drives the rod out, the rod raises the carriage or pulls the cables, and a check valve holds it up there until the lowering valve lets it back down. It's a simple, rugged part — until the rod seal wears or the barrel scores, at which point it can't hold pressure and the lift won't stay up.

What lifts this hydraulic cylinder fits

This hydraulic cylinder fits the lift models below. Click a model to open its visual parts breakdown — the exploded drawing with every part numbered, so you can confirm this is the right part for your exact lift before you order.

• Q4P07 — see the exploded parts breakdown for this lift

Replacing your hydraulic cylinder

Rebuilding a cylinder with a seal kit is bench work: tear it down, lay the parts out in order, confirm the bore and rod aren't scored, then reassemble with the new seals lubricated and bench-test for leaks before it goes back in. The order of the seals and the condition of the barrel make or break the job. Walk through the complete guide before you crack the end cap. Full step-by-step: how to replace a 2-post lift cylinder.

Find the right part for your lift

The surest way to get the right part is to work from your lift's own breakdown. open our Challenger parts lookup, choose your model, and every part is mapped on the drawing with its number and price. If you cannot find the model plate, our guide to finding your model number explains where each lift type hides it, and our phone line is open if you want a hand.

Signs of a hydraulic problem

Wipe the cylinder rod and body clean, cycle the lift, and look again. A film of oil creeping down from the rod seal means the seal is weeping; a wet fitting means an o-ring or washer is done. Then raise the lift, mark the height, and leave it overnight — if it has drifted down by morning, the cylinder, check valve, or lowering valve is bleeding internally.

Parts commonly replaced at the same time

While the system is open, take care of the companions — the seal kit, the o-rings, the feed hose, and the oil you will need to refill and bleed. It is cheaper and cleaner than reopening the system for the piece you skipped. We keep the right specs for your lift and can kit it for you.

Hydraulic fluid

Most 2-post and 4-post lifts run hydraulic oil equivalent to ISO-32; some older units were filled with Dexron ATF. Check what your lift currently uses and do not mix the two — and defer to your lift's installation manual for the exact fill capacity, since it varies by model.

Safety notes

Treat the hydraulic system as pressurized until you have relieved it. Bleed in the correct order, keep the reservoir topped so the pump never sucks air, and confirm there is zero drift at full height before returning the lift to service. A cylinder or hose that weeps today is a failure waiting for the worst moment.

Before you order

Hydraulic components are specific to the lift's pressure and plumbing, so order by model and serial, not by eye. For a leaking cylinder, decide between a seal kit and a full replacement first — we can help — and plan on topping off and bleeding the system when the new part goes in.

Confirm this is the right part before you order

Lift manufacturers revise parts mid-production without changing the model name, so the same lift bought two years apart can take two different revisions of the same component. Before you order, find the model plate on the lift — on most 2-post lifts it rides on one of the columns at eye level, on 4-post lifts it is usually on a column or the power-unit side runway — and note the full model number and serial. The serial dates the lift to a production run, and that is what decides which revision fits.

If the plate is painted over or missing, take a photo of the part you are replacing next to a tape measure and send it to us. Between the dimensions, the mounting pattern, and what lift it came off of, we can almost always identify the exact part before you spend money on the wrong one.

Why buy your Challenger hydraulic cylinder from Auto Lift Services

We install, inspect, and repair Challenger lifts every week — the TCS3-5-03-00 is a part we handle in the shop, not a random SKU we drop-ship. The phone answers if you have a question mid-install — call 800-674-9302 — and every part ships genuine, no aftermarket substitution unless you ask for it.
